CHARACTERISTICS
- Can be used with hinges with centres from 53 to 70 mm by moving the cement case accordingly.
- The cover on the jamb side must not be cut: there are 3 cover fixing positions on the case, to be selected on-site.
- The patented blocking system is unique and allows for regulating the height exceeding the height of the cement case by 5 mm or shimming the door closer by as much as 10 mm.
- Less deformation of the cement box due to the blocking device guarantees easier positioning and cover fixing.
- Blocking system is assured by means of 6 special screws, two each side of the cement case and two for longitudinal blocking, one from the spindle side and one from the opposite side.
- The cover is fixed with just 2 screws (not 4) in a central position, therefore protected from wear.
- The cement box has rounded corners, making it easier to break a hole in the floor.
- A special model cement box, blocking devices and stainless steel adjusting screws for installations in aggressive environments or for the food industry, hospitals, swimming pools, etc. are available.
- It is easy to insert the rear cover and it must be done when the cover and door are installed: it is not necessary to dismantle the door to remove it.
- "Thermo constancy" is standard equipment.
- One single valve programs the desired closing speed from 130° to 0° ca. An additional valve enables and regulates the latch speed from 15° to 0° ca.
- Refined and modern aesthetics.
 |
